RTD Sensor Duplex PT100 Double Elements 6-wire Mineral Insulated Probe
 |
Produktdetails:
| Herkunftsort: | China |
| Markenname: | GME |
Zahlung und Versand AGB:
| Min Bestellmenge: | 10 PCs |
|---|---|
| Verpackung Informationen: | Exportfall-Verpackung |
| Lieferzeit: | 2-3 Wochen |
| Zahlungsbedingungen: | L/C, T/T, Western Union, Paypal |
| Versorgungsmaterial-Fähigkeit: | 100.000 PCs |
Ausführliche Produkt-Beschreibung
| Typ: | Art J, K, T, E, N, S, FTE, fertigte besonders an | Temperaturbereich: | Maximales 1600℃ |
|---|---|---|---|
| Futterrohrmaterial: | Edelstahl | Kopfmaterial: | Aluminium, SS-Stahl, Bakelit, besonders angefertigt |
| Verdrahtung: | 2-wiring, 3 Verdrahtung, 4 Verdrahtung, Verdrahtung 6, besonders angefertigt | ||
| Hervorheben: | PT100 Duplex RTD Sensor,6-wire RTD Sensor,Mineral insulated RTD Sensor |
||
RTD Sensor Duplex PT100 Double Elements 6-wire Mineral insulated Probe
Product Features:
♦ Easy to install, several optional testing range
♦ Dual use for gas and liquid, used to various material compatible with 316L stainless steel
♦ Quick response, high accuracy
♦ Good long-term stability, low energy consumption,smart
Applicable Scope
♦ Pipe and ventilation systems
♦ Hydraulic and pneumatic systems
♦ Cooling and heating systems
♦ Water supply and water heating systems
♦ Air-conditioning systems
♦ Automation system temperature mensuration and control
Technical Index
| Sensor | Type J, K, T, E, N, S, PT100, PT1000, customized |
| Thermowell | Available |
| Signal line specification | 2-wiring, 3-wiring, 4-wiring, 6-wiring, customized |
| Accuracy | Class 1, Class 2 |
| Testing range(°C) | Max 1600℃ |
| Probe diameter | Φ3, Φ4, Φ5, Φ6, Φ8, Φ10, Φ12mm, customized |
| Response Time | T=50°C 2.3s;T=90°C 5.4s |
| Ambient Temperature | -40~+85°C |
| Storage Temperature | -40~+125°C |
| Environmental Protection | IP65 |
